Assembly of Alliance
ET920D Elliptical Trainer
REMOVE ALL SECURITY TAPE AND WRAPPING
BEFORE BEGINNING.
2. Attach both the Left and Right Rear Foot Frames (32, 33) to
the Left and Right Front Foot Frames (30,31) with Carriage Bolts
(62) and Locknuts (49).
1
2
1. Attach the Aluminum Extrusions (45) to the Main Frame
Assembly (1) with Screws (63). Connect the Aluminum
Extension Plate (34) between the Extrusions (45) with Screws
(64).
