Polar graphs
Directivity Index / Beamwidth Frequency / Power response, Input impedance
Specifications
Installation
(Tube Mount) (Wall Mount)
Architectural specifications:
The Ci Series Ci400 and Ci400T comprise
a 19mm aluminium dome tweeter and
100mm white polypropylene bass/mid unit
with double neo compound magnet
system. Performance should meet or
exceed the following criteria: frequency
response 1 metre on-axis with swept sinewave shall be 80Hz to 27 kHz,
sensitivity shall be at least 88dB for
2.83V@1m. The impedance and maximum
power shall be 50W at 4 ohms. The Ci
Series Ci400 and Ci400T is best suited
where high quality music and speech
reinforcement applications require hi-fi
performance such as: · Multi Room systems.
· Home Theatre systems.
· Lounges, Bars, Boutiques.
· Boardrooms & Offices.
· Airports, Convention Centres, Hotels.
· Live Theatre/Concert Hall fill-in.
· Houses of Worship.
· Sports Arenas.
Frequency range 80Hz - 27kHz
Sensitivity (2.83v @ 1m, 2π) 88dB
Rec. amplifier power 10 - 50W
Nominal Impedance 4Ω (min. 3.2Ω)
Crossover Frequency 2.8kHz
Enclosure material aluminium alloy
Terminals binding posts up to Ø5mm (0.2”)
conductor
Dimensions (H x W x D) 198 x 130 x 150 mm, 7.8 x 5.2 x 6 in.
Net weight 2.0kg (4.4lbs)
500Hz 1kHz
2kHz 4kHz
8kHz 16kHz
PL1602EN
1 Ci400 / Ci400T
2 Ci400 / Ci400T
5 Ci400 / Ci400T
1 Ci400 / Ci400T
2 Ci400 / Ci400T
6 Ci400T
