Pos. Description QTY Part #
1 Bed,Wagon Wood 1 8427‐182#01
2 Handle 1 8427‐182#02
3 Frame,Front 1 8427‐182#03
4 Base,Front Frame 1 8427‐182#04
5 Platform,Base 1 8427‐182#05
6 Frame,Rear 1 8427‐182#06
7 Brace,Rear Axle 2 8427‐182#07
8 Wheel 4 8427‐182#08
9 Hubcap Retainer 4 8427‐182#09
10 Washer ø16mm 4 8427‐182#10
11 Bracket 10 8427‐182#11
12 Screw,Round 8x1/2" 20 8427‐182#12
13 Bolt,Carriage M06X30 4 8427‐182#13
14 Washer ø12mm 9 8427‐182#14
15 Washer ø10mm 8 8427‐182#15
16 Bolt,Carriage M06X40 4 8427‐182#16
17 Bolt,Carriage M10x25 1 8427‐182#17
18 Washer ø20mm 1 8427‐182#18
19 Washer ø14mm 1 8427‐182#19
20 Nut,Hex M10 1 8427‐182#20
21 Cotter Pin 1 8427‐182#21
22 Bolt,Panhead M06x70mm 1 8427‐182#22
23 Rack,Rear 1 8427‐182#23
24 Rack,Front 1 8427‐182#24
25 Rack,Side 2 8427‐182#25
26 Grip,Hand (not illustrated) 1 8427‐182#26
27 Nut,Hex M06 8 10303005
28 Nut,Hexlock M06 1 NUT.HEXLOCK.M06
Spare Parts List for 8427‐182 Air Tire Wagon Classic Flyer by Kettler
