- 4 -
Technical Data
Number of threads 4 or 3
Number of needles 2 or 1
Sewing speed 1100 Revs/min
Stitch width 6 mm with 4 threads
6 mm or 4 mm with 3
threads
Stitch length 1 – 5 mm
Needles HA x 1 Nr. 11-14 or
130/705 Nr. 75-90
Power consumption : Motor: 90 W
Bulb: 15 W
Total: 105 W
Rated voltage: 230 V ~ , 50Hz
Protection class: II
Bulb power: 15 W
Bulb voltage: 230 V / ~50 Hz
Bulb thread: E14 thread
The sound intensity level under normal operating
conditions amounts to 78dB(A).
Foot pedal
Use only the foot pedal originally supplied with this
sewing machine:
- ELECTRONIC FDM Speed Controller
- Type KD-2902
Items supplied
Overlock Sewing Machine
Oil
Waste container
Accessory box
Operating instructions
Replacement
(upper blade)
2 Needles Nr. 11
4 Needles Nr. 14
(2 in the machine,
pre-installed)
4 Bobbin caps
4 Spool pin
(preinstalled)
Allen key
Flat-headed screw-
driver
Covering hood
Pincers
Brush
