7
KF-dB3 Parts list Rev A
Ref # Part # description Qty
1 223-00067 RAIL KPS-DB3 4
2 223-00963 UPRIGHT, LEFT FRAME KF-DB3 1
3 223-00964 UPRIGHT, RIGHT FRAME KF-DB3 1
4 206-00394 PLUG, 50.8X76.2 KF SERIES 2
5 206-00392 FOOT CAP, RIGHT 50.8 KF SERIES 4
6 202-00087 ALLEN BOLT, M10*25 8
7 202-00097 M10 SILVER WASHER 8
8 202-00093 WASHER, 10 16
11 206-00393 FOOT CAP, LEFT 50.8 KF SERIES 4
12 202-00659 SCREW, BUTTON HEAD SOCKET CAP M8X25 8
13 202-00094 WASHER 8, 9*28*2 8
14 206-00391 SQUARE PLUG, 50.8 KF SERIES 4
# 202-00683 BOLT PACK, KF-DB3 1
Parts list
