30

Parts List

REF #

PART #

DESCRIPTION

QTY

REF #

PART #

DESCRIPTION

QTY

U1T1 423-00083 MAIN FRAME, HT-740T

1

UAW12 410-00070 MOUNTING PART, HT-740T

1

U1T2 423-00084 BASE FRAME, HT-740T

1

UAS1

406-00240 PLASTIC FIXING BRACKET, HT-740T

1

U1T3 423-00085 MOTOR FAME, HT-740T

1

UAS2

406-00241 END CAP, HT-740T

2

UAT4 423-00086 LEFT UPRIGHT, HT-740T

1

UAS3

406-00242 MOTOR FAN, UAS3

1

UAT5 423-00087 RIGHT UPRIGHT, HT-740T

1

UAS4

404-00018 RUNNING BELT, HT-740T

1

UAT6 423-00088 LEFT HANDLEBAR, HT-740T

1

UAS5

406-00243 INSERT, HT-740T

1

UAT7 423-00089 RIGHT HANDLEBAR, HT-740T

1

UAS6

406-00244 CONSOLE TOP COVER, HT-740T

1

U1T8 423-00090 CONSOLE FRAME, HT-740T

1

UAS7

406-00245 CONSOLE BOTTOM COVER, HT-740T

1

U1T9 423-00091 ADJUSTMENT FRAME, HT-740T

1

U1S8

406-00246 LEFT MOTOR LIGHT COVER, HT-740T

1

U1T10 423-00092 SUPPORT FRAME, HT-740T

1

U1S9

406-00247 RIGHT MOTOR LIGHT COVER, HT-740T

1

U1G1 419-00038 RUNNING BOARD TUBE, HT-740T

1

UAS10 403-00012 LEFT CONNECTION BOARD, HT-740T

1

UAB1 419-00039 SIDE RAIL FIXED BOARD, HT-740T

4

UAS11 403-00013 RIGHT CONNECTION BOARD, HT-740T

1

UAB2 402-00225 SIDE RAIL WASHER, HT-740T

8

UAS12 406-00248 LEFT END COVER, HT-740T

1

UAJ1 402-00226 BOLT M10*62, HT-740T

1

UAS13 406-00249 RIGHT END COVER, HT-740T

1

UAJ2 402-00227 BOLT M10*45, HT-740T

1

UAS14 406-00250 END COVER CAP, HT-740T

2

UAJ3 402-00228 BOLT M8*30, HT-740T

2

U1S15 405-00025 EXTRUSION, HT-740T

2

UAJ4 402-00229 BOLT M8*26, HT-740T

4

U1S16 406-00251 MOTOR COVER, HT-740T

1

UAJ5 402-00230 BOLT M10*25, HT-740T

12

U1S17 406-00252 MOTOR COVER FRONT CAP, HT-740T

1

UAJ6 402-00231 BOLT M8*42, HT-740T

4

UAS18 406-00253 RING SHAPE CAP, HT-740T

2

UAJ7 402-00232 BOLT M8*50, HT-740T

6

UAS19 406-00254 MOVING WHEEL, HT-740T

4

UAJ8 402-00233 BOLT M8*80, HT-740T

1

UAS20 406-00255 MOVING WHEEL TUBE CAP, HT-740T

2

UAJ9 402-00234 BOLT M8*75, HT-740T

1

UAS21 402-00266 FLAT WASHER, HT-740T

4

UAJ10 402-00235 BOLT M8*20, HT-740T

4

UAS22 406-00256 CUSHION, HT-740T

2

UAJ11 402-00236 BOLT M6*25, HT-740T

8

UAS23 406-00257 INNER TUBE CAP, HT-740T

4

UAJ12 402-00237 BOLT M6-40, HT-740T

4

UAS24 406-00258 PLASTIC BEARING, HT-740T

2

UAJ13 402-00238 BOLT M8*65, HT-740T

2

UAS25 406-00259 WHEEL, HT-740T

2

UAJ14 402-00239 BOLT M8*40, HT-740T

1

UAS26 406-00260 SLIDE BLOCK, HT-740T

2

UAJ15 402-00240 SCREW M6*16, HT-740T

4

UAS27 404-00019 BELT, HT-740T

1

UAJ16 402-00241 SCREW M6*12, HT-740T

2

UAS28 406-00261 FOAM TUBE, HT-740T

2

UAJ17 402-00242 SCREW M5*6, HT-740T

13

UAS29 406-00262 LEFT PROTECTION COVER, HT-740T

1

UAJ18 402-00243 SCREW M5*10, HT-740T

4

UAS30 406-00263 RIGHT PROTECTION COVER, HT-740T

1

UAJ19 402-00244 SCREW ST2.9*9.5, HT-740T

13

UAS31 406-00264 LEFT INNER COVER, HT-740T

1

UAJ20 402-00245 SCREW ST2.9*6.5, HT-740T

28

UAS32 406-00265 RIGHT INNER COVER, HT-740T

1

UAJ21 402-00246 SCREW ST4.2*12, HT-740T

18

UAS33 406-00266 RUBBER PAD, HT-740T

8

UAJ22 402-00247 SCREW ST2.9*15, HT-740T

4

UAS34 406-00267 PIN BAR, HT-740T

1

UAJ23 402-00248 SCREW ST3.5*35, HT-740T

2

UAS35 406-00268 AXLE CAP, HT-740T

1

UAJ24 402-00249 SCREW ST4.2*12, HT-740T

6

UAD1

407-00132 CONSOLE, HT-740T

1

UAJ25 402-00250 SCREW ST4.2*9.5, HT-740T

16

UAD2

407-00133 HEARTBEAT BOARD, HT-740T

1

UAJ26 402-00251 SCREW ST4.2*19, HT-740T

2

UAD3

407-00134 QUICK ACCESS KEY BOARD, HT-740T

1

UAJ27 402-00252 FLAT WASHER M10, HT-740T

15

UAD4

407-00135 PULSE SENSOR, HT-740T

2

UAJ28 402-00253 FLAT WASHER M8, HT-740T

29

UAD5

402-00267 SAFETY KEY, HT-740T

1

UAJ29 402-00254 FLAT WASHER M5, HT-740T

4

UAD6

413-00094 AC SINGLE WIRE 6, HT-740T

1

UAJ30 402-00255 SPRING WASHER M8, HT-740T

6

UAD7

413-00095 AC SINGLE WIRE 7, HT-740T

1

UAJ31 402-00256 LOCK NUT M8, HT-740T

8

UAD8

413-00096 AC SINGLE WIRE 8, HT-740T

1

UAJ32 402-00257 LOCK NUT M10, HT-740T

1

UAD9

413-00097 INCLINE MOTOR CONNECTION WIRE, HT-740T

1

UAJ33 402-00258 SCREW M4*6, HT-740T

4

UAD10 413-00098 CONSOLE UPPER WIRE, HT-740T

1

UAJ34 402-00259 SCREW M32*3/8, HT-740T

1

UAD11 413-00099 CONSOLE LOWER WIRE, HT-740T

1

UAJ35 402-00260 SCREW M4*8, HT-740T

1

UAD12 413-00100 CONSOLE MIDDLE WIRE, HT-740T

1

UAJ36 402-00261 BOLT M1/4-20*2, HT-740T

2

UAD13 413-00101 ADAPTOR, HT-740T

1

UAW1 402-00262 SLEEVE TUBE, HT-740T

4

UAD14 407-00136 CONTROL BOARD, HT-740T

1

U1W2 409-00019 FRONT ROLLER, HT-740T

1

UAD15 406-00269 OVERLOADING PROTECTOR, HT-740T

1

U1W3 409-00020 REAR ROLLER, HT-740T

1

UAD16 408-00062 BREAKER, HT-740T

1

U1W4 419-00040 AXLE, HT-740T

1

UAD17 413-00102 POWER CABLE, HT-740T

1

U1W5 419-00041 LIMIT AXLE, HT-740T

1

UAD18 412-00033 DC MOTOR, HT-740T

1

UAW6 406-00239 SLEEVE, HT-740T

2

UAD19 412-00034 INCLINE MOTOR, HT-740T

1

U1W7 410-00068 GAS SHOCK, HT-740T

2

UAD20 402-00268 MAGNETIC RING, HT-740T

1

UAW8 402-00263 #6 ALLEN WRENCH, HT-740T

1

UAD21 413-00103 REED SWITCH, HT-740T

1

UAW9 402-00264 #5 ALLEN WRENCH, HT-740T

1

U1D22 403-00014 WALKING BOARD, HT-740T

1

UAW10 402-00265 WRENCH W/SCREW DRIVER, HT-740T

1

UAJ37

402-00269 LOCK NUT M6, HT-740T

8

UAW11

410-00069

COMPRESSING SPRING, HT-740T

1

UAD23 407-00138

SPEED INCLINE PCB, HT-720T

2

HT-740T PARTS LIST REV A
