KF-PTO Parts list Rev A
Ref # Part # description Qty
1 3-01048 CROSS BASE, KF-PTO 1
3-01049 FRAME, UPRIGHT KF-PTO 1
3 3-01050 FRAME, BASE KF-PTO
4 19-00497 WEIGHT BAR, KF-PTO
5 0-0039 FOOT CAP, RIGHT 50.8 KF SERIES 4
0-00393 FOOT CAP, LEFT 50.8 KF SERIES 4
7 0-0055 SCREW, BUTTON HEAD SOCKET CAP M1X75 4
8 0-0054 SCREW, BUTTON HEAD SOCKET CAP M1X100
9 0-0037 SCREW, M10X70 BUTTON HEAD SOCKET CAP
10 0-0013 HEX KEY 8
11 0-0009 NYLON NUT, M1
1 0-0001 ROUND PLUG 48 1
13 0-0000 PLUG 50.8*50.8 4
14 0-0001 ROUND PLUG 48 7
15 0-00 WASHER, 13XX KPSFI #3 1
1 0-0018 WASHER, 11*0*
17 0-004 WASHER, 9X1X1. 8
18 0-009 HEX KEY 8 1
19 0-00703 HEX KEY 5 1
0 0-0013 HEX KEY 1
8
Parts list
