4 UNCRATING
Parts Check
•
Open the parts box, and check the parts against the illustrations. There may be minor differences
between these illustrations and the actual vehicle parts. In the following charts under Remarks, D
= diameter in millimeters, and L = length in millimeters.
No. Part Name Qty Remarks
1 Handlebar with Grips, Weights and Clutch Lever Assy 1
Clamp, Handlebar 1
Socket Bolt, Clamp, Handlebar 4 D = 8, L = 30
Clamp, Front Master Cylinder 1
Socket Bolt, Clamp, Front Master Cylinder 2 D = 6, L = 22
2 Left Bracket, Lower Fairing 1
Flanged Bolt with Non-permanent Locking Agent, Left Bracket 2 D = 6, L = 14
Lower Fairing, LH & RH 2
Socket Bolt, Lower Fairing 6 D = 5, L = 16
Plastic Washer, Lower Fairing 6 D = 5.3
Socket Bolt, Lower Fairing 2 D = 6, L = 14
Plastic Washer, Lower Fairing 2 D = 6.5
Plastic Rivet, Lower Fairing 3
3 Windshield 1
Socket Bolt, Windshield 4 D = 5, L = 20
Plastic Washer, Windshield 4 D = 5.3
4 Battery Electrolyte, FTX12-BS 1 12 V 10 Ah
5 Owner’s Manual 1
