Specifications
15
Model VXT 4 VXT 6 VXT 8
Tweeter 1" Silk Dome NEO 1" Silk Dome Ferrite 1" Silk Dome Ferrite
Woofer 4" Woven Kevlar 6" Woven Kevlar 8" Woven Kevlar
Input Type
XLR-1/4" TRS Combo
10k Ohm Blanced
Pin 1 + Sleeve = Ground
Pin 2 + Tip = (+) High
Pin 3 + Ring = (-) Low XLR-1/4" TRS Combo
10k Ohm Blanced
Pin 1 + Sleeve = Ground
Pin 2 + Tip = (+) High
Pin 3 + Ring = (-) Low XLR-1/4" TRS Combo
10k Ohm Blanced
Pin 1 + Sleeve = Ground
Pin 2 + Tip = (+) High
Pin 3 + Ring = (-) Low
Controls
System Level Adjust
+6dB to -30dB Variable
Ground Lift
LFT (On) or GND (Off)
Clip Indicator
On, Off or Limit
Auto Mute
On or Off
HF Adjust - N/A
LF Adjust - N/A
System Level Adjust
+6dB to -30dB Variable
Ground Lift
LFT (On) or GND (Off)
Clip Indicator
On, Off or Limit
Auto Mute
On or Off
HF Adjust
+1dB, Flat, -1dB
LF Adjust
Whole Space (-3dB 52Hz)
Half Space (-3dB 60 Hz)
Quarter Space (-3dB 75Hz)
System Level Adjust
+6dB to -30dB Variable
Ground Lift
LFT (On) or GND (Off)
Clip Indicator
On, Off or Limit
Auto Mute
On or Off
HF Adjust
+1dB, Flat, -1dB
LF Adjust
Whole Space (-3dB 40Hz)
Half Space (-3dB 48 Hz)
Quarter Space (-3dB 62Hz)
Amp & Fusing
HF: 15 Watts
LF: 30 Watts
2.0A 100VAC 50HZ
2.0A 110-120VAC 50/60Hz
1.0A 220-240VAC 50/60Hz HF: 30 Watts
LF: 60 Watts
3.15A 100VAC 50Hz
3.15A 110-120VAC 50/60Hz
1.6A 220-240VAC 50/60Hz HF: 60 Watts
LF: 120 Watts
4.0A 100VAC 50Hz
4.0A 110-120VAC 50/60Hz
2.0A 220-240VAC 50/60Hz
Freq Response 56Hz - 22kHz +/- 2dB 49Hz - 22kHz +/-1.5dB 37Hz - 22kHz +/-1.5dB
Max SPL Music: 104dB
Peak: 107dB Music: 108dB
Peak: 111dB Music: 111dB
Peak: 114dB
Dimensions
10 1/16" H x7 1/3" W x 7 " D
25.6cm H x 18.6cm W x 17.7cm 14 1/2" H x 10 1/3" W x 9 5/8" D
36.8cm H x 26.3cm W x 24.6cm D 17 1/4" H x 12 1/2" W x 11 7/8" D
43.8cm H x 31.8cm W x 30.0cmD
Shipping Weight 14 lbs 27 lbs 41 lbs
Omni Mount Part 20.5 WBX 30.0 WBX 60.0 WBX
Screw Type M6 M6 M8
Screw Length 12.5mm Min. - 17.5mm Max. 13.5mm Min. - 20.0mm Max. 17.75mm Min. - 26.0mm Max.
