21
Spare parts list Dessin et liste des pièces de rechange Designación y lista de las piezas de recambio
pos. description part no.
1 front frame complete 1 91611230
2 locking pin complete 1 91640021
3 handlebar bushing (2046) 1 70122051
4 parental control locking mechanism (2970) 1 70121836
5 guide bushing for ø42mm (2969) 1 70121560
6 front frame plug (2995) 1 70128425
7 rear frame 1 91611234
8 plug 1 70121432
9 adjustement sleeve (3064) 1 70121607
10 quick release knob M12 1 91670120
11 tie rod covering, left 1 70121621
12 tie rod covering, right 1 70121620
15 rear wheel 2 15170103
16 cap for running wheel 2 70121869
17 sand bucket (3532) 1 70121837
18 wheel fork 1 91620358
19 front wheel complete 1 15170081
20 front wheel bearing 2 10116038
21 cap for front wheel (3491) 2 70121883
22 pedal (1848) 2 70121886
23 mudguard (4031) 1 70121529
24 handlebar with grips 1 91650346
25 grips 2 10111037
26 molded seat (3534) 1 70120208
27 covering (3497) 1 70121889
28 handlebar clamp 1 97201280
29 adaptor (3493) 1 70121891
30 hubcap 2 70121758
31 release latch for bucket (3533) 1 70121890
32 plug for Ø 8 mm 4 10100169
33 pushbar, lower part 1 97100400
34 grip, upper part (3378) 1 70121884
35 grip, lower part (3379) 1 70121885
