12
PARTS LIST
MODEL NO.: RA9430SQB
RA9436SQB
NO. DESCRIPTION MODEL / SIZE PART NO.
1 Duct Cover-Mounting Bracket C1-0203-0092
2 Duct Cover RA9236DC B102-0192
3 Plastic Plate C1-0506-0092
4 6” round Plastic Exhaust C1-0505-0001
5 Hood-Mounting Bracket C1-0221-0001
6 Rubber Stand C1-0510-0101
7 Hood Casing RA9430SQB RA-2530-A
RA9436SQB RA-25900-A
8 Wiring Box C1-0231-2590
9 Halogen Lights (12V 20W) C1-0403-0001
10 Air Chamber & Motor C1-0302-A120-01
11 Safety Screen C1-0602-0103
12 Control Panel Support C1-0207-2590
13 Control Panel C1-0404-4001
14 Electric Component Support RA9430SQB C1-0201-2530
RA9436SQB C1-0201-2590
15 Transformer (Light) C1-0402-0120-40
16 Transformer (Motor) C1-0402-A120-01
17 Capacitor C1-0401-0240-03
18 Processor Board C1-0404-0401-B
19 Baffle Filter B101-2590-15
