27 GB/MT
Introduction
improper usage. The appliance is not intended for
commercial use.
Q Equipment Components
1 Gear selector switch
2 Spirit level
3 Button - Battery condition / Battery display LED
4 Direction of rotation switch / lock
5 ON / OFF Switch / R.P.M. regulator
6 Bit storage
7 Button for battery release
8 Battery pack
9 Torque pre-selector
10 Drill chuck
11 Fast charger
12 Green charge-control LED
13 Red charge-control LED
Q Items supplied
1 Cordless Drill / Screwdriver X18V with battery pack
2 Double bits
1 Fast charger
1 Storage bag
1 Operating manual
1 Booklet “Warranty and Service”
Q
Technical Data
X18V 2 Speed Cordless Drill / Screwdriver /
KH3188:
Nominal no-load speed: 1. Gear: n
0
0 - 500 min -1
Nominal no-load speed: 2. Gear: n
0
0 - 1400 min -1
Nominal voltage: 18 V
Chuck size: 1,0 - 10 mm
Maximum Drill Diameter: Steel: 10 mm,
Wood:
30 mm
Variable torque levels: 1 - 8 Nm
Max. Torque:
18 Nm
X18V Battery Pack / KH3191:
Nominal voltage:
18 V
Capacity: 1,5 Ah
Energy content: 27 Wh
X18V Fast Battery Charger / KH3192:
Primary:
Nominal voltage:
230 V ~ 50 Hz
Nominal output: 60 W
Secondary:
Nominal voltage:
18 V
Charging current 2600 mA
Charging time: approx. 60 min
Protection class: II / &
Noise / vibration data:
Values determined in accordance with EN 60745
The sound pressure level (A-weighted) of the device
is typically 66 dB(A). Uncertainty K=3 dB.
The sound level while working can exceed 77 dB (A).
Wear ear protection!
Total vibration (vector sum of three directions) is
calculated in accordance with EN 60745:
Drilling in metal: Vibration emission value
a
h, D
= 1.944 m / s 2 ,
uncertainty K= 1.5 m / s 2 ,
Screwing: Vibration emission value
a
h
= 2.101 m / s 2 ,
uncertainty K= 1.5 m / s 2 .
WArNINg!
The vibration level given in these
instructions has been measured in accordance with
a standardised measurement procedure specified
in EN 60745 and can be used to compare devices.
Different uses of the device give rise to different
vibration levels and in many cases they may exceed
the values given in these instructions. It is easy to
underestimate the vibration load if the electrical
power tool is used regularly in particular circum-
stances.
Note: If you wish to make an accurate assessment
of the vibration loads experienced during a particular
period of working, you should also take into account
