MOTOR AND CONTROL PARTS
7
For Models: KSM150PS__1
W10122280
Illus. Part
No. No. DESCRIPTION
1
110679 Screw, Pivot
2
116241 Washer, Spring
3
Lever, Speed
Control Assy
9709276 Black
9709278 Buff
4
3183680 Spring, Control
Plate
5
3184176 Speed Link & Cam
6
240205 Spring, Flat
7
240769 Screw
8
9702695 Field Assembly
9 W10068260 Screw
10
16998 Stud, Governor
Drive
11
3180162 Washer
12 W10068270 Washer
13
9704324 Washer, Ball
Bearing (Front)
14
240775−1 Seal, End
15
3180526 Bracket, Bearing
Asm.
16
3180238 Washer
17
8533905 Nut
18
240680 Insert, Brush
Holder
19
9706416 Brush, Carbon
20
9707926 Screw, Set
21
116286 Cap, Spring
Seat
22
116287 Spring, Cap
23
Cap, Brush Holder
3184212 Black
3184213 Almond Creme
24
17830 Governor Assembly
25
240904−2 Control Plate
Assembly
26
Power Cord
9701025 White
9701026 Black
27
9706595 Phase Control
Board
28
9708315 Armature &
Bearing
29
4162634 Sleeve, Motor
Stud
30
3184609 Screw, Self
Tapping
31
3179908 Housing, Brush
Holder
32
4162546 Brush Holder
