4
ZX AMPLIFIERS
SPKR + SPKR - SPKR + SPKR -
L+ L– R+ R–
L L R R
REMOTE BASS
AUTO
TURN ON
+12V DC AUDIO
OFFSET LO
HI INPUT
SPKR + SPKR -
INPUT
SENSITIVITY
L
XOVER
OFF HI LO OUTPUT
L R R
SPKR + SPKR -
BRIDGED OPERATION (MONO)
minimum impedance of 4 ohms
ZXRC* REMOTE BASS
INSTALLATION
signal in
SPKR + SPKR - SPKR + SPKR -
L+ L– R+ R–
L L R R
1. mount the
metal bracket
* ZXRC not included
ZX450.2 ONLY
4-conductor phone cable
back view
2. slide the housing until it snaps
into the metal bracket
STEREO-AND-MONO-SIMULTANEOUSLY (SAMS) OPERATION
minimum impedance of 4 ohms bridged (mono)
and 2 ohms per channel stereo
signal in
hi pass hi pass
lo pass
signal out
signal out
woofer
woofer
