TECHNICAL SPECIFICATIONS - CHASSIS
»
TIGHTENING TORQUES - CHASSIS
Collar nut front axle
M16x1.5 40 Nm
Collar nut rear axle M20x1.5 80 Nm
Shock absorber top M10 45 Nm
Shock absorber bottom M10 45 Nm
Collar screws brake disk front/rear M6 (10.9) Loctite 243 + 10Nm
Screw brake caliper front (Enduro) M8 Loctite 243 + 25 Nm
Screw brake caliper front (Supermoto) M10 Loctite 243 + 45 Nm
Bearing bolt linkage arm/frame M12 60 Nm
Collar nuts rocker arm bolts M14x1.5 100 Nm
Engine mounting screw M10 45 Nm
Ball joint for push rod M8 Loctite 243 + 25 Nm
Sprocket screws on nuts M8 Loctite 243 + 35 Nm
Hexagon nut swingarm bolt M14x1.5 100 Nm
Clamping screws top triple clamp M8 20 Nm
Clamping screws bottom triple clamp M8 15 Nm
Clamping screws fork stubs M8 15 Nm
Screws handlebar clamp M8 Loctite 243 + 20 Nm
Allen head screw handle bar support M10 Loctite 243 + 20 Nm
Bleeder screw oil reservoir frame M16x1.5 25 Nm
Spoke nipple WS 7 4 Nm (3 - 6 Nm)
Other screws on chassis M6
M8
M10 10 Nm
25 Nm
45 Nm
Other collar nuts on chassis M6
M8
M10 15 Nm
30 Nm
50 Nm
