TERYX 750 4x4 LE TERYX 750 4x4 TERYX 750 4x4 NRA OUTDOORS ™
Engine type 4-stroke, liquid-cooled,
90
0 V-Twin
Displacement 749cc
Bore x stroke 85 x 66mm
Compression ratio 8.8:1
Carburetion Dual Keihin CVKR-D34
Ignition Digital DC-CDI
Electrical 12-volt DC; 14 amp-hour battery,
alternator
Drive train Automatic torque converter;
continuously variable belt-drive
transmission with high and low
range plus reverse and Kawasaki
Engine Brake Control
Final drive Dual shaft, selectable 4x4
Exhaust Muffler with USFS-approved
spark arrestor
Tires, front/rear Maxxis tubeless,
26 x 8-12/26 x 10-12
Suspension, front Independent A-arms with
adjustable gas-charged shocks
Suspension, rear Double wishbones with gas-charged
shocks with remote reservoirs
Wheel travel, front/rear 7.5/7.2 inches
Steering Rack and pinion
Brakes, front Discs with hydraulic 2-piston calipers
Brake, rear Sealed, oil-bathed multi-disc system
Fuel capacity 7.9 gallons
Dimensions (LxWxH) 115.8 x 58.3 x 75.4 inches
Wheelbase 75.8 inches
Ground clearance 11.3 inches
Cargo bed (LxWxH) 44.2 x 32.7 x 11.0 inches
Cargo bed load capacity 500 pounds
Towing capacity 1,300 pounds
Lights (2) 40-watt sealed-beam
headlights with tail/stoplight
Color(s) Realtree ® Hardwoods Green ® HD ™ ,
Sunbeam Red or Woodsman Green
Realtree ® Hardwoods Green ® HD ™
Sunbeam Red
Woodsman Green
Realtree ® Hardwoods Green ® HD ™ Realtree ® APG HD ™
Engine type 4-stroke, liquid-cooled,
90
0 V-Twin
Displacement 749cc
Bore x stroke 85 x 66mm
Compression ratio 8.8:1
Carburetion Dual Keihin CVKR-D34
Ignition Digital DC-CDI
Electrical 12-volt DC; 14 amp-hour battery,
alternator
Drive train Automatic torque converter;
continuously variable belt-drive
transmission with high and low
range plus reverse and Kawasaki
Engine Brake Control
Final drive Dual shaft, selectable 4x4
Exhaust Muffler with USFS-approved
spark arrestor
Tires, front/rear Maxxis tubeless,
26 x 8-12/26 x 10-12
Suspension, front Independent A-arms with
adjustable gas-charged shocks
Suspension, rear Double wishbones with gas-charged
shocks with remote reservoirs
Wheel travel, front/rear 7.5/7.2 inches
Steering Rack and pinion
Brakes, front Discs with hydraulic 2-piston calipers
Brake, rear Sealed, oil-bathed multi-disc system
Fuel capacity 7.9 gallons
Dimensions (LxWxH) 115.8 x 58.3 x 75.4 inches
Wheelbase 75.8 inches
Ground clearance 11.3 inches
Cargo bed (LxWxH) 44.2 x 32.7 x 11.0 inches
Cargo bed load capacity 500 pounds
Towing capacity 1,300 pounds
Lights (2) 40-watt sealed-beam
headlights with tail/stoplight
Color(s) Realtree ® Hardwoods Green ® HD ™ ,
Sunbeam Red or Woodsman Green
Engine type 4-stroke, liquid-cooled,
90
0 V-Twin
Displacement 749cc
Bore x stroke 85 x 66mm
Compression ratio 8.8:1
Carburetion Dual Keihin CVKR-D34
Ignition Digital DC-CDI
Electrical 12-volt DC; 14 amp-hour
battery, alternator
Drive train Automatic torque converter;
continuously variable belt-drive
transmission with high and
low range plus reverse and
Kawasaki Engine Brake Control
Final drive Dual shaft, Selectable 4x4
Exhaust Muffler with USFS-approved
spark arrestor
Tires, front/rear Maxxis Tubeless,
26 x 8-12/26 x 10-12
Suspension, front Independent A-arms with
adjustable gas-charged shocks
Suspension, rear Double wishbones with gas-
charged shocks with remote
reservoirs
Wheel travel, front/rear 7.5/7.2 inches
Steering Rack and pinion
Brakes, front Discs with hydraulic 2-piston
calipers
Brake, rear Sealed, oil-bathed multi-disc
system
Fuel capacity 7.9 gallons
Dimensions (LxWxH) 115.8 x 58.3 x 75.4 inches
Wheelbase 75.8 inches
Ground clearance 11.3 inches
Cargo bed (LxWxH) 44.2 x 32.7 x 11.0 inches
Cargo bed load capacity 500 pounds
Towing capacity 1,300 pounds
Lights (2) 40-watt sealed-beam
headlights with tail/stoplight
Color(s) Realtree ® APG HD ™
Sunbeam Red
Woodsman Green
