CONTROL PANEL - Controls description

1. Front right cooking zone control knob
2. Rear right cooking zone control knob
3. Central cooking zone control knob
4. Rear left cooking zone control knob
5. Front left cooking zone control knob
6. Multifunction oven temperature knob
7. Multifunction oven switch knob
8. Electronic programmer

Pilot lamps:

9. Oven temperature indicator light

10. Cooking hob ON indicator light

Fig. 2.1

A

U

T

O

8

7

5

4

3

2

1

6
