Getting To Know Your Bench Grinder
1
12
13
4 4
5
6
7
8
8
7
5
2
6
5
3
3
2
1. On/off switch
2. Tool rest
3. Tool rest locking knob
4. Eye shield
5. Eye shield locking knob
6. Spark deflector
7. LED work light
8. Wheel guard
9. Grinding wheel
10. Grinding wheel locking nut
11. Outer grinding wheel flange
12. Base
13. Mounting holes
