• 4 •
To charge, plug an extension cord into charger plug on the right side of 7.2
the Instant Power™. (Extension cord not included; must be purchased
separately.)
Plug the extension cord into 110V AC electrical wall outlet.
7.3
The red CHARGING LED will glow indicating charging. 7.4
The green LED will glow when the battery has reached full charge. This 7.5
could take up to 72 hours due to the age and condition of the battery. The
charger will automatically drop into a float mode and maintain the battery
at full charge without damaging the battery.
Charge the Instant Power™ as soon as possible after use.
7.6
12 VOLT DC POWER OUTLET CHART 8.
The Instant Power™ is a power source for all 12 volt DC accessories 8.1
equipped with a 12 volt accessory plug. Make sure the device to be pow-
ered is OFF before inserting 12 volt accessory plug into 12 volt DC acces-
sory outlet. Use for power outages, fishing, and camping trips. Estimated
usage time is listed in below chart:
Appliance Type Estimated
Wattage
Estimated Time
Cell Phones 4 Watts 30 Hours
Fluorescent
Lights
4 Watts 30 Hours
Radios, Fans 9 Watts 21 Hours
Depth Finders 9 Watts 21 Hours
Camcorders,
VCRs
15 Watts 12 Hours
Electrical Tools 24 Watts 7 Hours
Electrical Coolers 48 Watts 3 Hours
Car Vacuum,
Air Compressors
80 Watts 1.5 Hours
NOTE: Estimated run-times. Actual time may vary. Times are based on the
internal battery being fully charged.
The DC accessory outlet has a 15-amp automatic overload protection
circuit breaker. If an overload occurs, unplug (remove) accessory, and the
breaker will automatically reset.
USING USB PORT 9.
NOTE: The Jump Start + USB On/Off switch energizes both the jump
