SAME Range
230 270
• NEW DEUTZ COMMON RAIL, EURO III,
24 VALVES, 6 CYLINDER INTERCOOLED,
TURBOCHARGED AND ELECTRONICALLY
CONTROLLED ENGINES WITH EXTERNAL
EXHAUST GAS RECIRCULATION SYSTEM
• AUTOMATIC 4-RATIO POWERSHIFT GEARBOX,
MAX. 50 KM/H, LIMITED TO 40 KM/H AT
ECONOMY ENGINE SPEED (FOR LEGAL
PURPOSES)
• 540 ECON – 1000 RPM REAR P.T.O.
• ELECTRONICALLY CONTROLLED REAR LIFT
WITH 10,500 KG LIFTING CAPACITY
• 3 INDEPENDENT HYDRAULIC SYSTEMS
(TRANSMISSION, STEERING AND LIFT,
HYDRAULIC CONTROL VALVES)
• HYDRAULIC FRONT AXLE SUSPENSION
• PNEUMATIC CAB SUSPENSION
• FRONT LIFT WITH 5100 KG LIFTING CAPACITY
DIAMOND 230 270
Max power
HP/kW
249/183 275/202
Hom. power (2000/25/EC) at
nominal engine speed HP/kW
244/179 269/198
Cylinders/displacement n°/cc 6/7146 Turbo intercooler
Transmission
AUTOMATIC POWERSHIFT gearbox,
40 forward + 40 reverse gears with creeper,
shift-on-the-go hydraulic shuttle
Rear P.T.O. rpm 540 ECON/1000
Lifting capacity kg 10500
Weight kg 8410 9050
