19.0 TFT Active Matrix LCD Panel User Manual
English 8
DISPLAY MODE
Incoming Display Mode
Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz)
640X350 31.475 70.100
640X480 31.469 59.940
640X480 37.500 75.000
720X400 31.469 70.087
800X600 37.879 60.317
800X600 46.875 75.000
1024X768 48.363 60.004
1024X768 60.023 75.029
1280X1024 63.981
60.020
1280X1024 79.976 75.024
1. We offer you 10 available modes compatible with Windows.
2. If any interference occurs on your screen while you modulating your PC or OSD. It is normal.
3. To have Best quality present on the PC, remember to upgrade your video card Driver. We strongly recommend you
to choose a Mode listed in the table.
4. The other Modes may not be supported that are not list on the table above
5. You may use the power management on your computer. It’s good for last service life of the product.
Specification
LCD Panel Type
Viewing Angle
Contrast Ratio
Brightness
Response Time
Display Colors
Max Resolution
Pixel Pitch 19.0” TFT Active Matrix LCD Display
H:170° , V:170°
600 : 1 (Typical)
250 (Typical)
(15+10) 25 ms
16.7M colors
1280X1024(SXGA)
0.294mm(H)x0.294mm(V)
Input Signals RGB Analog
Video In*
DVI*
ANT* Video Level:0.7Vp-p(75Ω)
Sync TTL with 75Ω internal pull-up resistors
Frequency FH:30~79KHz
FV:56~75Hz
Auto Detect NTSC/PAL interlaced video with input
format of Composite video(AV) and S-video
Support digital RGB signal with TMDS signaling type
NTSC or PAL-
B /
G
, D /
K
, I , L /
L’
Compatibility PC Up to 1280X1024@75Hz(Non-interlaced)
Connector RGB Analog
DVI
Video In*
Audio
Power
ANT*
DPF Card**
D-sub 15-pins
DVI-D
S-Video, RCA jack*
Stereo Phone Jack, RCA-Jack(L/R)
12V/DC Power Jack
RF Tuner PH Type terminal
CF/Micro-drive/SM/SD/MMC/MS/MS PRO
Power Voltage
Consumption
Power saving mode
100-240V, 50/60Hz(universal) via external AC Adapter
Active < 48Watt Max
Standby < 3Watt
Internal Speaker 2Wx2(Stereo)
User Interface LED Indicator Active - Green
Off - Turn off
Standby - Orange
Operating Condition Temperature
Air Humidity 5°C~40°C
20% ~ 80% R.H.
Dimensions Physical 463mm(H) x 436mm(W) x 64mm(D)
Net Weight 6.6 Kg
DDC DDC1/DDC2B Compliant
Power Management VESA DPMS, EPA Energy Star
Regulation (Certifications) CE, FCC, VCCI, BSMI, UL/CUL
*Video In and DVI functions are optional.
** DPF (Digital Photo Frame) is select option.
