MOON P-7 Dual-Mono Preamplifier
Specifications
Configuration ......................................................... Fully balanced, dual-mono
Power Supply Transformers ..................................... 2 x 10VA (for audio); 1 x 10VA (controller circuitry)
Power Supply Capacitance ...................................... 44,000µF
Circuit Topology ...................................................... Open Loop
Balanced inputs (XLR) ........................................... 2 pairs
Single-ended inputs (RCA) ..................................... 4 pairs
Monitor Loop (RCA)................................................. 1 pair
Input Impedance ................................................... 22,000
Ω
Input Sensitivity ..................................................... 200mV – 4.0V RMS
Balanced outputs (XLR) .......................................... 1 pair
Single-ended outputs (RCA) .................................... 2 pairs (fixed and variable)
Output Impedance .................................................. 50
Ω
Gain Control ........................................................... M-eVOL
Gain ....................................................................... 9dB
Signal-to-noise Ratio (20Hz-20kHz) ......................... 115dB @ full output
Maximum Output Voltage (Balanced) ........................ 12 Volts
Maximum Output Voltage (Single-Ended) .................. 6 Volts
Frequency Response .............................................. 5Hz - 100kHz +0/-0.1dB
Crosstalk @ 1kHz ................................................... -115dB
Intermodulation Distortion ...................................... Unmeasureable
THD (20Hz - 20kHz) .............................................. < 0.002%
Remote Control ...................................................... All Aluminum Full-Function (FRM-2)
Display Type ............................................................ 8 character dot matrix LED
Power Consumption @ idle ..................................... 20 Watts
AC Power Requirements ......................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ..................................................... 40 lbs / 18 Kgs
Dimensions .............................................................. 18.75 x 5.5 x 16.5
Balanced Input and Output Pin Assignment:
Pin 1................................ Ground
Pin 2................................ Positive
Pin 3 .............................. Negative
NOTE: In the event that you require the RS-232 codes for your MOON P-7, please contact
Simaudio Ltd. directly by either email ([email protected]) or by toll-free telephone
(877-980-2400).
Fuse Replacement: For the 120V version use a 0.5A slow blow (5 x 20mm size).
For the 230V version use a 0.25A slow blow (5 x 20mm size).
____________________________________________________________________________________
Specifications 14
