MOON W-7m Mono Power Amplifier
Specifications
Configuration ......................................................... Dual Mono
Power Supply Transformers .................................... 2 x 0.5kVA
Power Supply Capacitance ...................................... 240,000µF
Class Of Operation ................................................. A/AB
Design .................................................................... Fully Balanced Differential
Input Impedance ................................................... 47,500
Ω
Input Sensitivity ..................................................... 1780mV
Output Device Type ................................................ Bipolars - 24
Output Power at 8
Ω ............................................... 500 Watts
Output Power at 4
Ω .............................................. 1000 Watts
Frequency Response .............................................. 10Hz - 200kHz +0/-3dB
Output Impedance ................................................. 0.005
Ω
Damping Factor (static) ......................................... 1600
Gain ...................................................................... 31dB
Signal-to-noise Ratio .............................................. > 106dB @ full power
Maximum Output Voltage ....................................... 60 Volts
Slew Rate .............................................................. 70V/µs
Maximum Current – Peak ........................................ 68 amperes
Maximum Current – Continuous .............................. 32 amperes
Crosstalk @ 1kHz ................................................... Not applicable
Intermodulation Distortion ...................................... Unmeasureable
THD (20Hz - 20kHz @ 1 watt) ................................ < 0.015 %
THD (20Hz - 20kHz @ 500 watts) .......................... < 0.04 %
Power Consumption @ idle ..................................... 40 Watts
AC Power Requirements ......................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ..................................................... 85 lbs / 38 Kgs
Dimensions (W x H x D, inches) .............................. 18.75 x 7.5 x 16.5
Balanced Pin Assignment: Pin 1................................ Ground
Pin
2................................
Positive
Pin
3
..............................
Negative
12 Volt Trigger:
Logic ............................... Direct (0V off, 12V on)
Jack.................................
3.5mm microphone jack
Input
Impedance ............. 1k
Ω
Current Consumption........ 12mA
NOTE: In the event that you require the RS-232 codes for your MOON W-7m, please contact
Simaudio Ltd. directly by either email ([email protected]) or by toll-free telephone
(877-980-2400).
Fuse Replacement:
For the 120V version use a 8A fast blow (3AG size).
For the 230V version use a 4A fast blow (3AG size).
