Page 11
9
TP-400-2001-05-IW-S
Handles and Controls (Later)
44
1916622
3
NUT, Hex Hd., 1/4-20
45
1916964
3
LOCKWASHER
46
1720238
1
ROD, Shift, Upper
47
1720240
1
ROD & ARM ASMY, Pivot
48
1715123
1
SPRING, Torsion
49
1668524
2
BLOCK, Pivot
50
1668185
2
BUSHING
51
1924361
1
WASHER
52
1921159
1
CAPSCREW, Hex Hd., 1/4-20 x 2-1/4
53
1668523
1
ROD & CLEVIS ASSY.
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693646
555M, 5HP Manual Start
1693647
555M, 5HP Manual Start (Exp.)
1693648
755M, 7HP OHV Manual Start
1693649
755M, 7HP OHV Manual Start (Exp.)
