Spalding M867SF12 - Manual (Page 10)

10 ID# M867SF12 08/06
While still in forward position, attach both
yokes (17) to pole as shown.
9.
22
17
17
THREE PEOPLE
REQUIRED FOR THIS
PROCEDURE. FAILURE
TO FOLLOW THIS
WARNING COULD RESULT
IN SERIOUS INJURY
AND/OR PROPERTY
DAMAGE.
WARNING!
20
12
12
21
21
3.2"
18"
IMPORTANT!
From the top of the pole to the top of the upper
yoke’s bracket should be approximately 3.2”.
From the bottom of the upper yoke’s bracket to
the top of the lower yoke’s bracket should be
approximately 18”.
SEE FIGURE B
YOKE PLACEMENT
FIGURE
B.
