Hopper & engine group – Simplicity BAKER 1692902 6/14E User Manual
Page 5
3
TP 400-2120-00-CS-SB
Hopper & Engine Group
1
1960507
12
SCREW, Button Hd., Hex socket,1/4-20 x 3/4
2
1098100
1
RETAINER STRIP, Hopper Guard
3
1095100
1
GUARD, Hopper
4
1709603
1
SUPPORT, Hopper Guard
5
1709403
1
BAG, Collection, 24” x 36”
6
3621100
1
HANDLE, Hopper
7
1926106
2
CAPSCREW, Hex Hd. 5/16-18 x 3-1/4, Grade 5
8
5001612
3
DECAL, Danger
9
3685100
1
DEFLECTOR, Discharge
10
1931277
13
NUT, Hex Whiz-lock, 5/16-18
11
1924361
2
WASHER, Plain,17/32 x 1-1/4 x 5/64
12
1714250
2
WHEEL & TIRE, 1.75 x 12”
13
1960519
2
PUSH NUT, 1/2” dia.
14
1925205
8
CAPSCREW, Hex Hd., 5/16-18 x 5/8
15
1928635
3
SCREW, Taptite, 3/8-16 x 1-1/4
16
1713099
1
ROD, Leg
17
1714939
1
CHIPPER CONE CASTING, 3”
18
1930642
12
FLANGE NUT, 2-way lock, 1/4-20
19
1921319
4
WASHER, Plain
20
1069100
1
CONE, Chipper, 3” Yellow
20
1709409
1
CONE, Chipper, 3” Orange
21
*
1
ENGINE
22
118403
1
SHIELD
23
1917356
8
LOCKWASHER, Spring, 5/16
24
1921515
4
CAPSCREW, Hex, 5/16-24 x 3/4
25
1714085
1
ENGINE PLATE ASSY.
26
1717124
1
DECAL, 6/14E Simplicity (Mfg. 1692902 only)
26
1717125
1
DECAL, 6/14E Baker (Mfg. 1692904 only)
27
2005612
1
GOGGLES
28
1018100
1
HOPPER-SHREDDER, Yellow (Mfg. No. 1692904 only)
28
1709401
1
HOPPER-SHREDDER, Orange (Mfg. No. 1692902 only)
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
* See your local Tecumseh deal for Engine parts and service.
The above parts group applies to the following Mfg. Nos.:
1692902 6/14E Chipper/Shredder (Simplicity)
1692904 6/14E Chipper/Shredder (Baker)
