SP-515
English 3
DEVILBISS 4-LITER SERIES DEVILBISS 5-LITER SERIES
Catalog Number 515UK 515DS, 515DZ 515KS, 515KZ, 515NS
Delivery Rate (Lower delivery rates 1 to 4 LPM 1 to 5 LPM
available for low flow applications)
Maximum Recommended Flow 4 LPM 5 LPM
Outlet Pressure 8.5 psig (58.6 kPa)
Electrical Rating 230 V, 50 Hz, 1.4 Amp 115 V, 60 Hz, 4.2 Amp 220-230 V~, 50 Hz, 1.7 Amp
230 V~, 60 Hz, 1.9 Amp
Operating Voltage Range 195-253 V~, 50 Hz 97-127 V~, 60 Hz 187-255 V~, 50 Hz
218-253 V~, 60 Hz
Oxygen Percentage 1-4 LPM = 93%±3% 1-5 LPM=93%±3%
Operating Altitude
(tested at 21°C only) Across the voltage range: Across the voltage range: Across the voltage range:
0-1500 M (0-4921 ft) No degradation of performance No degradation of performance No degradation in performance
Tested at nominal voltage only: Tested at 230V/50Hz only:
1500-3000 M (4921-9842 ft) Not recommended/Not tested No degradation in performance ~4% oxygen perfomance drop at 5 LPM
3000-4000 M (9842-13123 ft) Not recommended/ Not tested Not recommended/Not tested Not recommended/Not tested
Operating Environment Range* No degradation in performance across No degradation in performance across ~4% oxygen performance drop at 5 LPM
10°C to 35°C, humidity range of 30% to 75% the operating voltage range the operating voltage range and 35°C condition. No degradation in
(tested at sea level). (tested at sea level). performance across the operating voltage
range at other liter flows (tested at 670 M).
Power Consumption 295 Watts Average 400 Watts Average 230v / 50 Hz - 365 Watts Average
230v / 60 Hz - 435 Watts Average
Weight 53 lbs. (24.5 Kilograms) 52 lbs. (23.5 Kilograms) 53 lbs. (24.5 Kilograms)
Sound Level (ISO 8359:1996 from front) 50.5 dbA overall average 52.5 dbA overall average** 50.5 dbA overall average (50Hz)
Dimensions 27.75"H x 16"W x 14"D (70.5 x 40.6 x 35.6 cm)
Pressure Relief Valve 44 psig±3psig (303 kPa±21 kPa)
Operating System Time Cycle / Pressure Swing
For units equipped with an OSD, Units with serial numbers less than H20000: 85%±2% (The audible alarm will alert at approximately 75%)
the visible “low oxygen” indicator Units with serial numbers of H20000 and greater: 83.5%±1.5%
will activate at the following level (The audible alarm will alert at approximately 75%. At less than 60%, the red “service required” light will activate.)
Storage Conditions -40°C to 70°C, humidity range of 10% to 100%, including condensation
Equipment Class and Type Class II Equipment Double Insulated Type B Applied Part
Approval Body TUV CSA TUV
and IEC 601-1+A1+A2 CAN/CSA-C22.2 No. 601.1-M90 IEC 601-1+A1+A2
Safety Standard EN 60601+A1+A2 EN 60601+A1+A2
ISO 8359:1996 ISO 8359:1996
(515KZ excluded)
EMC Compliance To: IEC 601-1-2
*Note: The OSD performance at 10°C to 35°C, 95% R.H. through voltage range on the 515DS verified at 670m.
**Note: This corresponds with a sound level of 50 dbA overall average as measured according to the guidelines of the now defunct ANSI Z79.13-1981 standard.
Specifications subject to change without notice.
SPECIFICATIONS
