16 GB
Ge
tting Star
te
d
You can enjoy the connected component using the six speakers of the system.
• Portable audio source: A
• DIGITAL MEDIA PORT adapter: B
To connect the DIGITAL MEDIA PORT adapter
Connect a DIGITAL MEDIA PORT adapter (not supplied) to the DMPORT jack. For details, see
“Using the DIGITAL MEDIA PORT Adapter” (page 69).
Note
• Connect the DIGITAL MEDIA PORT adapter so that the V marks are aligned. When disconnecting, pull out while
pressing A.
3 Connecting the other components
CENTER SUBWOOFER DIGITAL IN
COAXIAL OPTICAL
FRONT R FRONT L SUR R SUR L
SPEAKER
TV HDMI OUT
SPEAKER EURO AV
OUTPUT(TO TV)
COAXIAL 75 AM FM
ANTENNA
DMPORT
DC5V
0.7A MAX
DMP ORT
DC5V
0.7A MA X
Rear panel
DIGITAL MEDIA PORT adapter
(not supplied)
Front panel
To the portable audio
source
Stereo mini-plug cord
(not supplied)
(USB) port (See page 60.)
A
