hoSe & SpRay GUN aSSeMBly paRTS lIST
hoSe & SpRay GUN aSSeMBly
ITeM paRT No. deSCRIpTIoN qTy
1 4-01103 Wand assy., side grip W/1/4”
coupler 35-1/” (Bg) 1
4-0146 spray gun, ap 1000 (Bg) 1
3 -000 coupler, 1/4” Female, Brass
(Bg) 1
4 nozzle, please see exploded Views For sizes
5 4-0093450Bc Hose, 3/8" x 50', 1 Wire Blue,
w/coupler (Bg-5737,
Bg-8037, Bg-303037) 1
4-0073450rc Hose, 3/8" x 50', Wire Blue,
w/coupler (Bg-304037,
Bg-35337, Bg-373537) 1
3
4
1
2
5
6
10
8
9
7
3
ITeM paRT No. deSCRIpTIoN qTy
6 -00 coupler, 3/8” Female, Brass 1
7 3-101 injector, detergent, non-adjust,
3-5 gpm, .083 1
8 -9040 clamp, Hose
9 4-0080000 tube, 1/4” x 1/” clear Vinyl 6 ft.
10 -1904 strainer 1
