Soleus Air LX-140 - Manual (Page 13)

13
manual.
2) Case
a. Keep the unit from being exposed directly to the sun for possible color
fading.
b. Clean the surface with a damp cloth. Dry it with a soft towel.
3) Storing the Unit for an Extended Period of Time or Transporting
a) Empty water by unplugging the water drainage stop at the back
towards the bottom of the unit
b) Unplug the unit.
c) The unit should be stored in a cool dry place.
TECHNICAL SPECIFICATIONS
MODEL LX-140
COOLING CAPACITY 14,000 BTU/H
HEATING CAPACITY 11,000 BTU/H
DEHUMIDIFYING CAPACITY 65 pts/Day
COOLING 1610W POWER
HEATING 1610W
AIR FLOW VOLUME 177 CFM
POWER SOURCE 115 V~ 60 HZ
11/14 AMP
HEATING/COOLING
SOUND PRESSURE LEVEL 46 dB(A)
NET WEIGHT 84 Lbs
COOLING 60.8℉-108℉ OPERATING
TEMPERATURE
HEATING 23℉-89.6℉
ASSEMBLED 19
1
/
4
x17
3
/
4
x32
1
/
2
Inch DIMENSIONS
PACKAGE 20x35x23 Inch
REFRIGERANT R22
NOTE:
1) The above cooling capacity is measured at ambient temperature of DB 86 F, WB 78 F.
2) Noise level is measured at the point where is 3.28 ft away from the front of the unit, in cooling mode.
3) Power consumption is measured when fan runs at the highest speed Specifications above are for reference only.
Please see the actual data printed on the nameplate.
4) If the environment temperature is higher than the max operating temperature or lower than the min operating
temperature, the air conditioner may not work properly.
