V-Switch 3440 PRoDuct SPeciFicAtioNS
US Tel: 1-800-471-2616 International Tel: +972-3-767-4800
www.sanrad.com Copyright SANRAD 2008. All rights reserved.
V-Switch 3800 PRoDuct SPeciFicAtioNS
Storage Virtualization and
Volume Management
Maximum number of servers
supported: 200
Maximum number of volumes
supported: 51,200
Maximum capacity: 4096 TB (4.096 PB)
Maximum volume size: 64 TB
Fc interfaces
4 FC ports
Copper SFP HSSDC2
Optic LC SFP SW/LW
1, 2 or 4 Gb/s auto speed detection
L,N or NL ports
Management interfaces
RS232 DB-9 port
Ethernet 10/100 RJ45 port
Network interfaces
3 1Gbit iSCSI Ethernet ports
Copper RJ45 1000BaseT
Optic SFP 1000Base-SX
Optic SFP 1000Base-LX
internet Standards
RFC 791 IP v4
RFC 793 TCP, RFC 894 IP/Ethernet
RFC 1042,IP/802
RFC 1517
RFC 792 ICMP, 950 ISSP
RFC 3720-iSCSI
SSH-2
RFC 854 Telnet
Fibre channel ANSi Standards
FC-AL-2
FC-PLDA
FC-FLA
FC-PH-3
FCP
Management Standards
SNMP V2
RFC 2863
RFC 2011
RFC 2012
ID SCSI MIB 05
ID iSCSI MIB 09
ethernet Standards
IEEE 802.3z
IEEE 802.3.ab
wake up on LAN
Removable compact Flash
Dimensions
1.75”H x 17.2”W x22.8’’ D
(4.4 H x 43.8 W x 58 D cm).
Standalone surface mounting or
fits standard 19 inch EIA rack
Power
Dual Hot Swap Power Supplies
100-250V, 50-60Hz Auto Switching,
250 WATT
weight
14.1 lb (6.4 kg)
operating temperature
32° to 122°F (0°-50°C)
Storage temperature
-40° to 75°F (-40°-167°C)
humidity (non-condensing)
10 to 95%
Altitude
-500ft to -10,000ft; (-152m -3050m)
Regulatory compliance
EMC (Emission):
USA & CANADA: FCC part 15 Class A
Europe and Rest of the World:
EN55022 Class A
Immunity: EN55024
Safety
USA & CANADA: UL60950
Japan: EN60950
Europe and Rest of the World:
EN60950
environment
RoHS 6 Compliant
cRoHS Compliant
WEEE Compliant
StoragePro Management GUI
Rear View of V-Switch
Typical Installations
V-Switch 3440
