Parts identification, Main unit – Sony TA-FE370 User Manual
Page 4
4
GB
BALANCE 8 (8)
BASS 0 (8)
EON LINK (TA-FE570 only) qd (8)
INPUT SELECTOR 4 (8, 9)
LOUDNESS 6 (8)
PHONES jack qf (8)
SOURCE DIRECT 7 (8)
SPEAKERS selector qa (8)
STANDBY indicator 1
TAPE1 MONITOR (TA-FE570 only) qs (9)
TREBLE 9 (8)
VOLUME control 5 (8)
?/1 (power) 2 (8, 9)
(remote control sensor) 3 (5)
Parts Identification
Main unit
The items are arranged in alphabetical order.
Refer to the pages indicated in parentheses ( ) for details.
2
5
4
1
3
qf
qd
qs
qa
0
9
8
7
6
