AW120 Front-loading Washer
Automatic Wash Cycles
Cotton (Heavy, Regular, Light) •
Permanent Press
(Heavy, Regular, Light, Delicates) •
Handwashables (Light, Silk, Wool) •
Rinse, Spin, Drain Cycles •
Additional buttons
On/Off Button w/LED •
Four Wash Option Buttons (Soaking,
Extra Rinse, Easy Iron, PreWash)
•
Additional Dials
Wash Temp. Selector •
Multiple Spin Reduction Selector
0, 400, 500, 600, 700, 800, 1000,
1200 rpm
Additional Features
Stainless Steel Tub •
State of Wash Indication Knob
Auto Sensors Auto Load Balance, Auto Water Level
Automatic Laundry Aid Dispenser •
Technical Information
Voltage/Amps 120V / 13A (15A Circuit)
Drum Size 1.9 CF
Washing Capacity 12 lbs.
Color Available White
Door Opening Diameter / Swing 10 ½” / 150
Overflow / Flood Protection •
Self-Cleaning Pump •
Power Cord Length 6ft.
Adjustable Feet 4
Water Usage Up to 16 gallons
ENERGY STAR® •
Suspension System 2 Springs / 2 Shocks
Dimensions 32 3 / 4 ”H x 23 ½”W x 22 ½ ” D
Weight 154 lbs.
Motor Triphase - quiet operation
Installation Clearances (cULus®) 0” Sides, 1” Front/Back
AS66VX Vented Dryer
Automatic Dry Cycles
Timed Drying Cycles (Regular,
Perm Press, Delicates)
20-170 min.
Auto Dry (Regular) •
Air Fluff •
Easy Iron •
Additional buttons
Start Button •
Low Heat / High Heat Button •
Additional Features
Time Remaining Display Knob
Sequence Indicator Knob
Door Opening, Swing 14”, 170°
Door Style Round, with window
Bi-Directional Drum Rotation •
Removable Lint Filter •
Technical Information
Voltage/Amps 120V / 12A (15A Circuit)
Drum Size / Drying Capacity 4 CF / 13 lbs.
Color Available White
Stainless Steel Drum •
Adjustable Feet 4
Vent Location Lower, Left-Rear
Dimensions 32 ¾”H x 23 ½”W x 22 ½”D
Optional RV/Marine Stack Kit Part No. SK02
Stacked Height 66 ¼”H (Subtract ¾” when using SK02)
Weight 67 lbs.
Closet Installation Clearances
(cULus®) ½” Top
¾” Sides/Rear/Front
Alternative Closet Installation
Clearances (cULus®) 4” Top, 0”Sides
¾” Rear/Front
Sp
ec
ifi
ca
tio
ns
su
bj
ec
t t
o
ch
an
ge
w
ith
ou
t n
ot
ic
e
The dryer’s color-coded
dial counts down the
dry time as the program
progesses. ‘Auto Dry’ stops
automatically when the
load is dry!
A large dryer lint
filter is located
in the front of the
drum to make
cleaning easier
than with other
brands
