Chassis mounted parts – Stellar Industries SI-60 User Manual
Page 65
59
Assembly Drawings 59
Item
PN
Description
Qty.
1
45054 SUB-FRAME FRONT WELDMENT
1
2
45059 SUB-FRAME FRONT WELDMENT
1
3
46134 PLATE SUBFRAME EXTENDER CLAMP
2
4
46062 MOUNTING BRACKET RSRVR SI60
2
5
46063 TUBE RSRVR MOUNTING SI60
2
6
45600 MOUNT BRKT TRUCK FRAME LUG SI60
2
7
47089 NUT 0.63-18 HHGR5 NYLOC
2
8
C1038 WASHER 0.63 USS FLAT ZINC
2
9
45762 PLATE SUBFRAME CLAMP BTTM SI60
2
10
45761 PLATE SUBRAME SHIM SI60
4
11
45760 PLATE SUBFRAME CLAMP SI60
2
12
47088 CAP SCR 0.63-18X2.50 HHGR5
2
13
47531 PIN PIVOT
1
14
45144 PIN 2.50 KP60 DROP SHAFT
1
15
45758 FLAT 0.50X4.00X0.75
4
16
45757 TUBE 3.00X3.00X.19WX3.50
2
17
47852 WASHER FLAT 2.56IDX3.25ODX0.25 THCK
8
18
45756 COLLAR 2.51X3.25X1.50 W/HOLE
4
19
0507
CAP SCR 0.50-13X4.50 HHGR5
4
20
C6106 NUT 0.50-13 HHGR5 NYLOC
4
21
45597 HANDLE PROP SI60
2
Chassis Mounted Parts
