OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Components
Indicator Lights: The steam cleaner has
an indicator light located at the base of the
unit that will illuminate when the unit is
plugged into the 120V wall outlet.
Red Light: When the red indicator light
illuminates, this indicates that the power is
“On”.
Green Light: When the green indicator
light illuminates, the steam is ready.
CAUTION: Read the instructions for
“Filling or Refilling Your Steam Cleaner
with Water” before opening the safety filler
cap.
CAUTION: Always unplug before filling.
ALLOW UNIT TO COOL FOR FIFTEEN
(15) MINUTES BEFORE REFILLING.
IMPORTANT: Do NOT add cleaning
solutions, scented perfumes, oils or any
other chemicals to the boiler in this
appliance. Use tap water or
distilled/purified water if the tap water
in your area is very hard.
Attaching the Shoulder Strap
Using the detachable shoulder strap
allows for greater freedom of
movement when both hands are
needed for various cleaning tasks. To
attach the shoulder strap to the steam
cleaner, simply snap the shoulder strap
hooks onto the connecting rings on the
unit body. (Fig. 12)
Using Your Steam Cleaner
After you have assembled the steam
cleaner and are ready to use:
1. When you press the steam trigger it
will lock in place and you will have
continuous steam.
2. To stop the flow of steam, press the
steam trigger release button.
3. When using the unit with the
shoulder strap, avoid rocking or
tilting the unit excessively as this
may cause water to enter the hoes
and be discharged along with the
steam.
Fig. 2
WARNING: Extreme care should be
taken when refilling the unit. Allow unit
to cool for15 minutes before refilling.
When refilling the steam cleaner while the
boiler is still hot, there is a risk that
water will squirt back during filling and
cause scalding. Use caution when
opening the filler cap as the cap may
become hot during use and escaping
steam can cause scalding.
5. To attach the concentrator nozzle or
the steam/garment diffuser to the
nozzle: align the two pins on the end
of the concentrator nozzle or
steam/garment diffuser with the
notches in the nozzle of the unit.
(Fig. 2)
6. Push the attachment into the nozzle
unit it stops against the unit. Turn
clockwise ¼ turn to lock the
attachment into place. Allow
approximately 5 minutes for vapor
to reach its working temperature and
pressure. When the unit is ready for
use, the green indicator light will
illuminate. Always point the nozzle in
a safe direction. At the start, some
water will come out from the nozzle.
This is normal.
NOTE: When the steam cleaner has run
out of water, steam output will cease.
CAUTION: This appliance is under
pressure. After every use, press steam
trigger button until all pressure has been
released before removing safety cap. Allow
unit to cool for fifteen (15) minutes before
refilling.
Unit
Nozzle
Steam/Garment
Diffuser
Fig. 1
Connecting
points
Connecting
points
Filling or Refilling Your Steam
Cleaner With Water
Fig. 12
IMPORTANT: Always insure that the unit
is “UNPLUGGED” from the wall receptacle
prior to initial filling or re-filling the water
tank and has been allowed to cool. Never
attempt to fill this unit under a water tap,
always use the measuring cup and
funnel provided.
IMPORTANT: When using the
steam cleaner with the shoulder
strap, avoid rocking or tilting the unit
excessively as this may cause water
to enter the hose and be discharged
along with the steam.
1. Before filling or refilling the steam
cleaner, make sure that the unit is NOT
plugged in and has been allowed to cool
for fifteen (15) minutes.
2. Press the locking steam trigger on the
handle of the unit to vent any residual
steam that is in the boiler.
3. Place the unit on a flat, stable surface.
Slowly, press and turn the filler cap
counter clockwise until it is removed.
4. Place the funnel in the tank opening.
(Fig. 1) Fill with a maximum of one filling
flask or 9.5 oz (280 ml) of water. Do Not
Overfill. Turn the safety cap clockwise
to replace.
NOTE: To remove or replace the filler cap,
push down and rotate it clockwise to tighten
or counter clock-wise to loosen.
NOTE: Filling the unit with hot water will
shorten the heat up time.
