25
ACCESSORIES
HARDWARE BAG KIT #6-3192 (for Model 8246)
PART NO. DESCRIPTION
9-0717 NUT, 5/16-18 Hex Nyloc (2)
9-1603 NUT, 1/4-20 Hex Nyloc
9-0760 BOLT, 5/16-18 x 2" Square Neck Carriage (2)
9-1298 NUT, 5/16-18 Hex Nyloc (2)
9-1082 PIN, 3/32 x 3/4” Cotter (2)
9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
HARDWARE BAG KIT #6-3191
(for Models: 9266E, E9266, 11306, E11306
PART NO. DESCRIPTION
9-0717 NUT, 5/16-18 Hex Nyloc (2)
1-2080 CABLE TIE, 7” (2)
9-1603 NUT, 1/4-20 Hex Nyloc
9-0760 BOLT, 5/16-18 x 2” Square Neck Carriage (2)
9-1298 NUT, 5/16-18 Hex Nyloc (2)
9-0001 BOLT, 5/16-18 x 3/4" Short Neck Carriage (2)
9-0187 WASHER, 5/16 Split Lock (2)
9-0196 NUT, 5/16-18 Hex (2)
9-1082 PIN, 3/32 x 3/4” Cotter (2)
9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
MANUAL No. 06069 LARGE FRAME SNOWTHROWER
