MOON W-7 Dual-Mono Power Amplifier

Specifications

Configuration ......................................................... Dual Mono
Power Supply Transformers .................................... 2 x 0.5kVA
Power Supply Capacitance ...................................... 115,520µF
Class Of Operation ................................................. A/AB
Design .................................................................... Fully Balanced Differential to output stage
Input Impedance ................................................... 47,500

Ω

Input Sensitivity ..................................................... 980mV
Output Device Type ................................................ Bipolars - 12 per channel
Output Power at 8

Ω ............................................... 150 Watts per channel

Output Power at 4

Ω .............................................. 300 Watts per channel

Output Power – Bridged Mono at 8

Ω ....................... 600 Watts

Frequency Response .............................................. 10Hz - 200kHz +0/-3dB
Output Impedance ................................................. 0.01

Ω

Damping Factor (static) ......................................... 800
Gain ...................................................................... 31dB
Signal-to-noise Ratio .............................................. > 106dB @ full power
Maximum Output Voltage ....................................... 34 Volts
Slew Rate .............................................................. 42V/µs
Maximum Current – Peak ........................................ 42 amperes
Maximum Current – Continuous .............................. 18 amperes
Crosstalk @ 1kHz ................................................... -105dB
Intermodulation Distortion ...................................... Unmeasureable
THD (20Hz - 20kHz @ 1 watt) ................................ < 0.015 %
THD (20Hz - 20kHz @ 150 watts) .......................... < 0.04 %
Power Consumption @ idle ..................................... 40 Watts
AC Power Requirements ......................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ..................................................... 85 lbs / 38 Kgs
Dimensions (W x H x D, inches) .............................. 18.75 x 7.5 x 16.5

Balanced Pin Assignment: Pin 1................................ Ground

Pin

2................................

Positive

Pin

3

..............................

Negative

12 Volt Trigger:

Logic ............................... Direct (0V off, 12V on)

Jack.................................

3.5mm microphone jack

Input

Impedance ............. 1k

Ω

Current Consumption........ 12mA


NOTE: In the event that you require either the RS-232 codes for your MOON W-7 or would like to

operate this amplifier in a bridged mono configuration, please contact Simaudio Ltd. directly

by either email ([email protected]) or toll-free telephone (877-980-2400).

Fuse Replacement:

For the 120V version use a 8A fast blow (3AG size).
For the 230V version use a 4A fast blow (3AG size).

____________________________________________________________________________________

Specifications

11
