Medalist Pro Installation Guide, Rev. B 19
Table 2b. DC power requirements (Amps) for LW/LC
models
Notes for Tables 2a and 2b.
[1] Measured with an average reading DC ammeter. Instanta-
neous +12V current peaks will exceed these values.
[2] A –10% droop is permissible during initial start of the spindle
but must return to ±5% before reaching 7,200 RPM. The
ST39140
LW/LC ST34520
LW/LC
Voltage +5V +12V +5V +12V
Regulation [5] ±5% ±5% [2] ±5% ±5%[2]
Max. operating
current DC
[1] 0.81 2.4 0.81 2.4
Avg. idle current
DCX [1]
0.53 0.90 0.53 0.90
Max. starting
current
(peak DC) DC [3]
(peak AC) AC [3] 2.5
N/A 2.5
N/A
Delayed motor
start (max)
DC [1] [4] 0.51 0.16 0.51 0.16
Peak operating
current
Typical DCX [1][6]
Maximum DC
[1]
0.58
0.81 1.0
1.53 0.58
0.81 1.0
1.37
