10X Pan-Tilt Speed Dome Camera
HTSD10X
Specifications
Image Sensor
..................................
1/4" Sony Super-HAD ™ CCD
Total Image Pixels
............................
NTSC: 811(H) * 508(V) 410K
PAL: 795(H) * 596(V) 470K
Number Of Effective Pixels
................
NTSC: 768(H) * 494(V) 380K
PAL: 752(H) * 582(V) 440K
Horizontal resolution
........................
More Than 540 TV Lines
Lens
..............................................
Optical: 10x Optical Zoom (F=3.8 to 38mm)
Digital:10x (100x with optical)
Day & Night (ICR)
............................
Auto/ Day/ Night
Min. Shooting Distance
.....................
0.35m (Wide) / 0.8m (Tele.)
Digital Slow Shutter
.........................
2/4/8/16/24/32/64/128/ OFF
Min. Illumination
.............................
Normal mode: 0.7 Lux (50IRE)
Night mode: 0.02 Lux (ICR On)
Luminance S/N Ratio...................................More than 50dB
Video Output
..................................
VBS:1.0Vp-p/75 Ohm
BLC
...............................................
ON / OFF
Flickerless
.......................................
NTSC: ON / OFF (1/100)
PAL: ON / OFF (1/120)
White Balance
.................................
AWB/ATW/INDOOR/ OUTDOOR
Pan Rotation Angle
...........................
360˚ Endless
Pan Speed
.......................................
Manual: 10˚ ~ 200˚/sec.
Preset: Max. 200˚/sec.
Tilt Rotation Angle
...........................
0˚ ~ 90˚
Tilt Speed
.......................................
Manual: 10˚ ~ 200˚/sec.
Preset: Max. 200˚/sec.
System Accuracy
..............................
0.02˚
Presets
...........................................
164 positions with a 16-character label available for each position
with different speed steps
Group Tour
.....................................
Max. 8 programmable group tours (each one consisting of up
to 60 preset steps with different steps)
Auto scan
.......................................
Programmable auto scan
Pattern
...........................................
8 programmable patterns (total 400 seconds)
Privacy Zone
...................................
4 privacy zones
Sector
............................................
8 selectable sectors with 16 characters
Password Protection
.........................
Yes
Alarm Input
....................................
4 alarms OFF / NC / NO (with various programmable states)
Alarm Actions
..................................
Activate preset, group scanning or patterns
Auto Flip
........................................
ON / OFF
OSD Menu
......................................
Multiple languages on screen
Communication
...............................
RS-485
Protocol
.........................................
Pelco D/P
Power Consumption
.........................
9W Max.
Power Supply
..................................
12V DC @750mA
Construction
...................................
Die-cast, anti-vandal dome cover
Dimensions
.....................................
6.6” (H) 6.6” (D) 3.9” (H)
Weight
...........................................
3.3 lbs.
Motor Type
.....................................
Stepper Motor
Micro Steps
.....................................
1/4 Step
Storage Temperature
........................
-40˚F to +140˚F
Operating Temperature
.....................
-14˚F to +120˚F
Certifications
..................................
CE, FCC
