SIR-KEN1 Installation Guide
System Connection Examples
System 1: Kenwood Headunit and SIR-KEN1
System 2: Kenwood Headunit, DVD/CD Changer and SIR-KEN1
SIR-KEN1
SIR-KEN1
KENWOOD COMPATIBLE
SIRIUS SATELLITE RADIO TUNER
Optional Kenwood SIRIUS-READY Headunit (5L-Bus CD Player or
Mobile Multimedia Station)
a
HEAD UNIT
CHANGER
ANTENNA
Optional Kenwood CD Changer
Optional Kenwood SIRIUS-READY Headunit (5L-Bus CD Player or
Mobile Multimedia Station)
a
SIR-KEN1
SIR-KEN1
KENWOOD COMPATIBLE
SIRIUS SATELLITE RADIO TUNER
HEAD UNIT
CHANGER
ANTENNA
