Sunfire ICO-E-20-M - Manual (Page 2)

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: 905-624-0260
Fax: 905-624-5669
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: 081-561-0433
Fax: 081-848-0041
40"
(1016mm)
40"
(1016mm)
10-7/8"
(276mm)
16-7/8"
(429mm)
36"
(914mm)
CL
L
L
C
C
10-1/4"
(260mm)
CABLE ENTRANCE
CABLE
ENTRANCE
64"
(1626mm)
8"
(203mm)
11-1/2"
(292mm)
32"
(813mm)
30"
(762mm) 31-1/2"
(800mm)
60"
(1524mm)
6"
(152mm)
44-1/2"
(1130mm)
8-1/2"
(216mm)
28"
(711mm)
SINGLE OVEN DOUBLE OVENS
Su
nfi
re
Ele
ctr
ic C
on
ve
cti
on
O
ve
ns
Form# SXICOE10 (07/07)
Width Depth
Height Oven Interior Dimensions Combustible Wall Clearance
ICO-E-10 ICO-E-20 Height Depth Width Sides Rear
40"
(1016mm)
44-1/2"
(1130mm)
60"
(1524mm)
72"
(1829mm)
20-1/2"
(520mm)
28-1/2"
(723mm)
29"
(736mm)
6"
(152mm)
6"
(152mm)
Model
Shipping
Lbs./Kg Cube
ICO-E-10 550/250 58.0
ICO-E-20 1100/495 114.0
Model
Entry Clearances
Crated Uncrated
ICO-E-10 47"
(1194mm)
32-1/2"
(826mm)
ICO-E-20
NOTE: ICO-E-10 w/Optional Casters - Overall Height = 65-1/2" (1664mm)
ICO-E-20 w/Optional Casters - Overall Height = 71-1/2" (1816mm)
Model
Total kW
Load
Nominal Amperes Per Line
208V / 3Ø* 240V / 3Ø*
X Y Z X Y Z
ICO-E-10 11.0 32 32 28 28 28 24
ICO-E-20 22.0 60 65 60 52 56 52
* Not convertible to single-phase
Double Deck Models require individual power supply connections
