SATO LM400E User Manual
Page 28
Adjusting Pitch Sensor
1
Open the side cover.
Side cover
2
To adjust the pitch sensor position,
Slide the green pitch sensor knob
at the far end of the slide guide.
It is located at the backmost (on the
sensor frame side).
Pitch sensor
Pitch sensor knob
3
Close the side cover.
When closing the cover, please
be careful not to get your fingers
caught in the cover.
Caution
18
