• Record evidence of theft, shoplifting, and accidents to take to the police.
• Set and forget, records continuously the past months activities from 4 cameras, no tapes required!
Common Scenarios
• Who drove the car that day?
• Who started that fight?
• Who's been going into my office?
• Who's using the photocopier/printer for personal use?
• Who's been stealing from the stationary cabinet?
• What time did the cleaner arrive & leave?
• Who's the neighborhood thief/vandal?
Home/Office Security System
4 Channel Digital Video Recorder
With Motion Detection and Audio
Technical Specifications
Video Format: NTSC/EIA or PAL/CCIR
HDD Supported: IDE type, UDMA 66, upto 250 GB
HDD supported
Recording Mode: Manual / Alarm / Timer / Motion
Camera Input Signal: Composite video signal 1Vp-p
(BNC) 4 channels
Main Monitor Output: Composite video signal 1Vp-p (BNC)
Call Monitor Output: Composite video signal 1Vp-p (BNC)
Audio Input: 4 audio inputs, (RCA)
Audio Output: 2 audio outputs from one
at a time, (RCA)
Motion Detect Area: 16 x 12 targets per camera
Motion Detect: 99 Levels
Video Loss Detection: Yes
Monitoring Speed: Up to 100 images/sec. for PAL
Recording Speed: Up to 25 images/sec. for PAL
Dwell Time: Programmable (1~15 Sec)
Picture in Picture: Yes (Movable)
Key Lock: Yes
Camera Title: 8 letters
Video Adjustable: Hue/ Colour/ Contrast/
Brightness Adjustable
Alarm Input: TTL input, Hi (5V),
Low (GND)
Alarm Output: COM./N.O/N.C
Remote Control: RS-232 or RS-485
Power Source: (19VDC) PSU Supplied -
Can Operate off 12VDC
Operating Power: <32W
Operation Temperature: 10 ~ 40º C
Dimensions (mm):
343(W) x 223(L) x 59(H)
Net Weight: 2.05 Kg
Package Contents
DVR
Hard Drive Tray & Key
Power Adaptor
Power Cable
6 x BNC to RCA Adaptors
Instructional Manual (Manual only available in English)
Molex Power Clip
