SMOOTH 6.25 MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
12
ASSEMBLY
STEP 3:
Connect the Upper Section Computer Wire (7) to the Lower Section 7 Pin Control Wire (24) and the Upper Section
Safety Key Wire (78) to the Lower Section Safety Key Wire (52). Insert any extra cable length into the Left Upright
(13).
Insert the Left and Right Uprights (13 and 14) into the Base Frame (36) and secure by tightening the two Bolts (105)
as shown in FIG 2. The two Bolts (105) are preassembled to the Base Frame (36) at the factory.
36
13
14
36
105
D
D
14
36
13
52
24
7
78
105
