Specifications
Specifications are correct at the time of printing and are subject to change without notice.
ENGINE:
8 HP* Tecumseh
Make Tecumseh
Model Snow King
Horsepower 8 @ 3600 rpm
Displacement 19.43 Cu. in (318.3 cc)
Oil Capacity See Engine Owner’s Manual
9 HP* Briggs & Stratton
Make Briggs & Stratton
Model Intek Snow
Horsepower 9 @ 3600 rpm
Displacement 18.6 Cu. in (305 cc)
Oil Capacity 28 oz. (,84 L)
CHASSIS:
Wheels
- 860, 960 Tire Size: 16 x 4.8
Inflation Pressure: 20 psi (1,37 bar)
Spout Rotation 210 Depress
Impeller 12” (30cm) 4 Blade Ribbon Flighted Steel
Auger Opening Height 19” (47.5 cm)
Drive System
Friction Disc, 5 Forward Speeds, 2 Reverse
DIMENSIONS
Effective Clearing Width
-860
26” (65cm)
-960 26” (65cm)
Length
-860
54” (137cm)
-960 54” (137cm)
Height
-860
43” (109cm)
-960 43” (109cm)
Weight
-860
236 lbs (107kg)
-960 235 lbs (106kg)
