COLLECTOR HOUSING, BELTS, PULLEYS, AUGER
ITEM
PART NO.
DESCRIPTION
1
4-1850
WELDMENT, Blower Housing
2
1-8796
CABLE, Clutch
3
9-0584
BOLT, 1/4-20 x 1/2” Hex Flange Lock (2)
4
9-1283
BOLT, #10-24 x 5/8”Flat Head Carriage (4)
5
9-0372
NUT, 1/4-20 Hex Center Lock
6
4-1952
STRAP, Engine
7
9-0187
WASHER, 5/16 Split Lock (no longer used with item 13)
8
2-8427
SCRAPER, Blade
9
1-0008
KEY, #6 x 5/8” Woodruff
10
2-8363
PULLEY, Engine
11
2-8312
BLADE, Wear Indicator
12
1-4098
WASHER, .343 I.D. x 1” O.D. Flat
13
7-2621
SCREW, 5/16-24 x 3/4” Hex Head Cap w/patch lock, Grade 5
*
6-1382
KIT, Engine Pulley (Includes items 10, 12, 13 & 1 item 7)
14
9-1079
NUT, #10-24 Hex Flange Lock (5)
15
9-1075
SCREW, #10-24 x 5/8” Self-Tap
16
3-2345
GUIDE, Belt
17
9-0981
SCREW, #10-32 x 1/4” Slotted Hex Washer Head, Self-Tap (20)
18
5-1506
ASSEMBLY, Idler Arm
19
1-4722
PULLEY, Idler Arm
20
9-1067
NUT, 5/16-18 Hex Center Lock (2)
21
9-1076
WASHER, 5/16 Flat (2)
22
1-4920
SPRING, Idler Brake
23
1-4919
SPACER, Bearing
24
1-4608
BEARING, Auger (2)
25
4-2722
RETAINER, Bearing (2)
26
1-0935
WASHER, 3/4” Flat
27
1-8635
PULLEY
28
4-1947
BELT, Auger 32.89
29
1-9753
COVER, Belt
--
5-2309
ASSEMBLY, Auger (Includes items 30 thru 33)
30
4-7027
AUGER Structure 20”
31
1-4612
SHOE, Flight, Center (2)
32
9-1286
SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Sems) (28)
33
2-9565
SHOE, Flite (4)
**
6-0631
KIT, Flite Shoe (Includes 2 item 31 & 4 item 33)
34
4-1958
DECAL, Model (Recoil)
--
4-6308
DECAL, Model (Electric Start)
35
4-6307
DECAL, Model, Auger Housing (Recoil)
--
4-6309
DECAL, Model, Auger Housing (Electric Start)
36
5-1560
ASSEMBLY, Bracket/Bushing (Includes 36A & 36B)
36A
3-2459
BRACKET, Cable Guide
36B
1-5146
BUSHING, Nylon
37
9-1084
SCREW, 1/4-20 x 3/8” Hex Washer Self-Tap (4)
38
4-1953
BRACKET, Fuel Tank
39
9-1070
NUT, 1/4-20 Hex Flange Lock, Grade 5
40
9-1246
SCREW, 1/4-20 x 3/4” Pan Head Self-Tap (Torx)
41
9-1064
BOLT, 1/4-20 x 1/2” Short Neck Carriage, Grade 5 (4)
42
9-0361
SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
*NOTE:
Order Complete Assembly by Kit Number.
**NOTE:
Order items 31 & 33 by Kit Number.
