1. Connect the power cord to the auxiliary power outlet
on the rear panel of your amplifier or receiver or to a
household AC outlet.
2. Connect the unit output terminals to the PHONO jack
of your amplifier or receiver.
Output terminals Amplifier (Receiver)
L (White) >> L Channel
R (Red) >> R Channel
GND (Spade) >> GND
NOTE:
• Be sure to connect the ground terminal firmly to the
amplifier or receiver.
• If this connection is not made or is loose, a power
source "HUM" will result.
1. Rotate the power dial clockwise to turn on the
power, the speed indicator and the
strobe-illuminator will light up.
2. Place a record on the slip mat, when playing a
45rpm record with a large center hole, place the
45-rpm adaptor on the center spindle.
3. Set the rotation speed (33/45) to match the record.
4. Remove the stylus protector, release the arm clamp.
5. Press the Start/Stop button, the turntable platter will
start to rotate.
6. Move the tonearm over the desired groove.
7. When play is finished, move the tonearm to the arm
rest, secure the tonearm with the arm clamp.
8. Press the Start/Stop button to stop the platter
rotating, rotate the power dial to turn off the power.
• For best results & proper care of your equipment use
Stanton Vinyl Cleaner (VC-1) for your records and Stylus
Cleaner Kit for styli (SC-4).
• Clean the stylus periodically with a soft brush to
prevent the accumulation of dust.
• When the sound becomes distorted or noisy, check
the stylus. If worn out, replace it with a new one.
• Any volatile materials such as alcohol, thinner, benzine,
etc., may remove the paint or damage the lustre,
please avoid.
APPLICATION:
This specification applies to the belt drive turntable unit T.50
STANDARD TEST CONDITION:
Ambient Temperature
20 +/- 2 degC
Relative Humidity 65% +/- 5%
NOTE: Measurements can be carried out between 5 degC to 35 degC and 45% to 85% relative humidity.
TURNTABLE SECTION:
Type
2-speed full manual
Motor DC motor
Driving Method Belt drive
Speeds 33
1
/
3
and 45rpm
Wow and Flutter Less than 0.2% WRMS (JIS WTD) with 33
1
/
3
rpm
Pitch Controls +/-10%
Starting Time Less than 1 sec. with 33
1
/
3
rpm
Braking Time Less than 1 sec. with 33
1
/
3
rpm
Time for Speed Change Less than 1 sec. from 33
1
/
3
to 45 rpm.
Less than 1 sec. from 45 to 33
1
/
3
rpm.
Audio Output Phono output
CONNECTIONS
OPERATION
MAINTENANCE
SPECIFICATIONS
