Motherboard Description
SY-P4I845PEISA/GEISA
11
A +12V
Power
Connector
B
MIC & LAN LED Connector
C
ATX Power Supply connector
D
Davicom Lan Chip
E
Socket 478 Connector
F
Intel 845GE North Bridge Chip
G AGP
Slot
H DDR
DIMM
Banks
I
CPU Cooling Fan (Fan1, 2) Connector
J
5V Stand-By Indicator LED
K
Bus Mastering EIDE/ATAPI Ports
L CMOS
Clear
Jumper
M 3V
Lithium
Battery
N
Front Panel Connectors
O
Intel 82801DB South Bridge Chip
P
32-bit PCI Slots
Q USB
2.0
Connector
R
Floppy Disk Drive (FDD) Port
S
Serial Infrared (IrDA) Device Header
T Flash
BIOS
U
ITE I/O Chip Smart Card Reader Connector
V
Chassis Cooling Fan (Fan1, 2) Connector
W
Smart Card Reader Connector
X
COM 2 Connector
Y 16-bit
ISA
Slots
Z
ISA bus IRQ and DMA control
AA
PCI-to-ISA bus conversion
AB AUX-IN
Connector
AC CD-IN
Connector
AD AC
97
Codec
Chip
AE Back
panel
Connectors
