F-26642-8 © Copyright 2010 Schneider Electric All Rights Reserved. 11
C - Left and Right
1/2
1/2
Center the
Universal Bracket in the Slot
6 x 2
5. Center bracket in slot.
6. Drill two holes.
7. Start one screw.
8. Swing bracket down.
x 1 7
8
#8 Sheet Metal
Screw
1
1
1
.8
.6
.4
.2
0
D- Right
C
11
L Centerline
14
13
5°
9
12
9. Loosen clamp nuts.
10. Check that the shaft is in full zero position.
11. Swing actuator
5° in the direction of travel. Do not move shaft.
12. Tighten clamp nuts to 4 to 6 lb-ft (5.4 to 8.2 N-m) of torque.
13. Move bottom of actuator back into position.
14. Pivot bracket back into position.
11
C L Centerline
14
13
5°
1
.8
.6
.4
.2
0
1
.8
.6
.4
.2
0 R
10
0°
12
1
.8
.6
.4
.2
0
1
.8
.6
.4
.2
0
9
12
0°
10
L
D- Left
5
