12
REMOTE CONTROL
TIMER SET BUTTONS
ON/OFF BUTTON
TEMP SET BUTTONS
SLEEP MODE
MODE BUTTON
FAN SPEED
LCD Display -
shows all settings
OPERATING THE UNIT USING THE REMOTE CONTROL
REMOTE CONTROL OPERATING INSTRUCTIONS
1) Power On and Off - Press the I/O button on the remote to turn the unit on or off.
2) Send - Press this button to transmit the chosen operation. This button must be pressed after every
operation change using the remote.
3) Mode Selection - Press the MODE Button repeatedly to cycle between the different modes: Auto, Air
Conditioner, Dehumidifier, and Fan only mode. NOTE: Heat mode can be selected using the re-
mote control, however heat mode is not functional on this unit.
4) Cooling Mode - Press the MODE button to choose the cooling option. Once cooling mode is selected,
choose the desired fan speed and temperature and then press the SEND button to transmit the operation.
5) Dry - Press the DRY Button to engage dehumidifier mode. Once DRY mode is selected, choose the de-
sired fan speed and temperature, then press the SEND button to transmit the operation.
6) Fan Speed - Press the FAN speed button to cycle through low, medium, and high fan speeds.
7) Temperature Setting - When the unit is in Air Conditioner mode you can select your desired
temperature. Press the + F or - F buttons to select your desired temperature setting. The temperature on
the LCD display will increase or decrease accordingly.
DRY MODE
TIMER BUTTON
F
I/O
F
